Figure 5-19 Adding a UL33 UPS
Table 5-6 UL33 UPS parameters
Select 3 from the drop-down list box.
NOTE
The setting example indicates that the UL33 UPS is connected to the
COM2 port of the RS485 card in slot 3 of the ECC500. If the UL33 UPS is
connected to another port, set the slot number for the connected port.
Select 2 from the drop-down list box.
NOTE
The setting example indicates that the UL33 UPS is connected to the
COM2 port of the RS485 card in slot 3 of the ECC500. If the UL33 UPS is
connected to another port, set the number of the connected port.
In this example, set Equipment Address to 1. Set the actual
device address of the UL33 UPS during operations.
The default timeout interval is 2s. Set the parameter to the required
value.
Step 4 Click Add Equipment.
----End
Follow-up Procedure
If the device addition fails, check whether the settings are consistent with the device
parameters.
