Huawei FusionModule800 User Manual

Indicator Color Name Status
RF_Z Green Wireless
communication status
indicator
● Steady on: No
network parameters
exist, or a network
is to be created.
● Blinking at long
intervals: A network
is set up, and no
node access is
allowed (the
indicator blinks at
0.5 Hz, on for 1s
and then
o for 1s).
● Blinking at super
short intervals: A
network is set up,
and node access is
allowed (the
indicator blinks at
10 Hz, on for 0.05s
and then
o for
0.05s).
● Blinking
intermittently at
super short
intervals: The access
actuator is
searching for a
network (the
indicator blinks at
super short intervals
for 0.5s and then
turns
o for 0.5s).
Communications Ports
The access actuator provides one DO port (LOCK/GND) and one DI port (GATE/
COM). Table 3-51 lists the LOCK/GND/GATE/COM port pin denitions.
Table 3-51 LOCK/GND/GATE/COM port pin denitions
Item
Description
LOCK/GND
(control
magnetic
locks) pin
sequence
LOCK 12 V_OUT
GND GND
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 77
