N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
You have removed the riser card above the TPM. For details, see 5.12 Removing the
Riser Card.
Data
You have determined the position on the N2000H V3 for removing a TPM.
You have obtained the rack number and chassis number of the N2000H V3.
You have located the N2000H V3 based on the preceding information, and labeled its
panel to prevent misoperations.
Tools
ESD gloves ESD wrist strap
M3 Phillips screwdriver
Packaging materials, for example, an ESD bag
Procedure
Step 1 Determine the TPM position. See Figure 5-31.
Figure 7-31 Determining the TPM position
Step 2 Unscrew the TPM using a Phillips screwdriver. See step (1) in Figure 5-32.
