N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Querying the Default IP Address
Table 7-1 lists the default IP address of the iBMC management network port.
Table 9-1 Default IP address
Querying and Setting the IP Address in the BIOS
Step 1 Restart the Appliance.
1. Click on the menu bar on the remote virtual console.
For details about how to log in to the remote virtual console, see 7.4 Logging In to the
Remote Virtual Console.
2. Select Reset
The system displays "Are you sure to perform this operation?"
3. Click Yes.
The Appliance restarts.
4. Press Delete repeatedly when the screen shown in the following figure is displayed
during the Appliance startup.
Figure 9-1 BIOS startup screen
5. Enter a BIOS password as prompted. The screen for setting the BIOS is displayed.
