4 NE40E-X3 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
103
Indicator/Butto
n
Description
interface)
ACT indicator
(amber) (on
Ethernet
interfaces)
If the indicator is blinking, data is being transmitted.
If the indicator is off, no data is being transmitted.
Table 4-10 describes the interfaces on the MPU and their uses.
Table 4-10 Interfaces on the MPU and their uses
Interface Name
Connector
Type
Description
MGMT-ETH
(10M/100M/1000M
Base-TX
auto-sensing)
RJ45
It connects to the NMS workstation and has LINK
and ACT indicators.
Console interface
RJ45
It connects to the console for on-site configuration
of the system.
AUX interface
RJ45
It connects to the Modem for remote maintenance
through dialing.
CLK interface
RJ45
External synchronous clock interface
TOD interface
RJ45
External synchronous time interface
Interface Attributes
Table 4-11 lists the attributes of the 10Base-T/100Base-TX/1000Base-T-RJ45 interfaces.
Table 4-11 10Base-T/100Base-TX/1000Base-T-RJ45 interface attributes
Attribute
Description
Connector type
RJ45
Operation mode
10M/100M/1000M auto-sensing interfaces, supporting half-duplex and
full-duplex modes
Standard
compliance
IEEE 802.3-2002
Cable
specification
Category 5 unshielded twisted pair (UTP) cables recommended when
the interface rate is 10 Mbit/s or 100 Mbit/s; super category 5 Shielded
Twisted Pair (STP) cables recommended when the interface rate is
1000 Mbit/s
