Attributes
Description
attributes
XFP modules, see Table 6-56)
Working mode
Full-duplex
Link protocol
PPP or HDLC
Network
protocol
IP
Table 6-56 Attributes of 10G XFP optical modules
Attributes
Description
Maximum
transmission
distance
10 km ( 6.21 mi. )
40 km ( 24.86 mi. )
80 km ( 49.71 mi. )
Center wavelength
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload optical
power
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber type
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical module transceiver supports two types of multi-mode
optical fibers with different cores. Table 6-57 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type, which is not delivered by Huawei.
If this type of optical fiber is required, you need to purchase it additionally.
Table 6-57 The transmission distance of 10G XFP optical modules
Core (μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2-300 ( 1.24 - 186.42 )
50
500
2-82 ( 1.24 - 50.95 )
62.5
200
2-33 ( 1.24 - 20.51 )
