Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
221
Component
Description
Hz), it indicates that the system is in the alarm state.
L/A (green)
If the indicator is steady on, it indicates that the link is normal. If the
indicator blinks, it indicates that data is being transmitted. If the
indicator is off, it indicates that the link is Down.
Interface Attributes
Table 6-76 lists the interface attributes of the 10-Port 10GBase LAN/WAN-XFP Line
Processing Unit S.
Table 6-76 Interface attributes of the 10-Port 10GBase LAN/WAN-XFP Line Processing Unit S
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module. (For the attributes of
XFP modules, see Table 6-77)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-77 Attributes of 10G XFP optical modules
Attributes
Description
Transmission
distance
0.3 km ( 0.19
mi. )
10 km ( 6.21
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
850 nm
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-7.3 dBm
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
