Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
222
Attributes
Description
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical transceiver supports two types of multi-mode optical fibers
with different cores. Table 6-78 lists the relationship between the core, the modal/bandwidth,
and the transmission distance. During configuration, the length of optical fibers is restricted
by the transmission distance. In addition, the optical fiber with the 50-um core and
2000-MHz*km modal/bandwidth is a special type, If this type of optical fibers are required,
you need to purchase it additionally.
Table 6-78 The transmission distance of 10G XFP optical modules
Core Fiber(μm)
Modal/Bandwidth(Mhz*
km)
Transmission
distance(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~ 50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
Technical Specifications
Table 6-79 lists the technical specifications of the 10-Port 10GBase LAN/WAN-XFP Line
Processing Unit S.
Table 6-79 Technical specifications of the 10-Port 10GBase LAN/WAN-XFP Line Processing
Unit S
Item
Specifications
Silkscreen
of the
board
name
LPUS-100
10x10GBase LAN/WAN-XFP
Power
consumpti
on(Typica
l value)
About 366 W
Heat
dissipation
1187.46 BTU/hour
Board
weight
About 9.5 kg ( 20.95 lb )
Dimensio
ns (width
x depth x
height)
400 mm x 530 mm x41 mm ( 15.75 in. x 20.87 in. x 1.61 in. )
