Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
247
Interface Attributes
Table 6-115 lists the interface attributes of the 1-Port 100GBase-CFP Integrated Line
Processing Unit (LPUI-101).
Table 6-115 Interface attributes of the 1-Port 100GBase-CFP Integrated Line Processing Unit
(LPUI-101)
Attribute
Description
Connector type
SC/LC
Optical
interface
attributes
Compliant with the selected CFP optical module. (For the attributes of
CFP modules, see Table 6-116)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-116 Attributes of 100G CFPoptical modules
Attributes
Description
Transmission distance
10 km ( 6.21 mi. )
10 km ( 6.21 mi. )
Center wavelength
1310 nm
1550 nm
Minimum transmitting
power
-4.3 dBm
-2.8 dBm
Maximum transmitting
power
4.5 dBm
3.5 dBm
Receiving sensitivity
-8.6 dBm
-8.8 dBm
Overload power
4.5 dBm
3.5 dBm
Optical fiber type
Single-mode
Single-mode
Technical Specifications
Table 6-117 lists technical specifications of the 1-Port 100GBase-CFP Integrated Line
Processing Unit (LPUI-101).
Table 6-117 Technical specifications of the 1-Port 100GBase-CFP Integrated Line Processing
Unit (LPUI-101)
Item
Specifications
Silk screen of the board name
LPUI-101
