Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
352
Indicator
Description
FPIC is in the alarm state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-273 lists the interface attributes of the 2-port OC-48c/STM-16c POS-SFP FPIC.
Table 6-273 Interface attributes of the 2-port OC-48c/STM-16c POS-SFP FPIC
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected SFP optical module. (for the attributes of
SFP modules, see Table 6-274)
Working mode
Full-duplex
Link protocol
PPP or HDLC
Network
protocol
IP
Table 6-274 Attributes of 2.5G SFP optical modules
Attributes
Description
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
1310 nm
1310 nm
1310 nm
1550 nm
Minimum
transmitting
power
-10.0 dBm
-5.0 dBm
-2.0 dBm
-2.0 dBm
Maximum
transmitting
power
-3.0 dBm
0 dBm
3.0 dBm
3.0 dBm
Receiving
sensitivity
-21.0 dBm
-21.0 dBm
-30.0 dBm
-30.0 dBm
Overload
optical power
-3.0 dBm
0 dBm
-9.0 dBm
-9.0 dBm
Optical fiber
Multi-mode
Single-mode
Single-mode
Single-mode
