Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
536
Indicator
Description
indicator(green)
If the indicator is blinking, the data is being read or written.
If the indicator is off, the link is Down.
Interface Attributes
Table 6-561 lists the interface attributes of the 4-Port 10GBase WAN/LAN-XFP Flexible
Card.
Table 6-561 Interface attributes of the 4-Port 10GBase WAN/LAN-XFP Flexible Card
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module. (for the attributes of
XFP modules, see Table 6-562)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-562 Attributes of 10G XFP optical modules
Attributes
Description
Maximum
transmission
distance
0.3 km ( 0.19
mi. )
10 km ( 6.21
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
850 nm
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-7.3 dBm
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
optical power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
Multi-mode
Single-mode
Single-mode
Single-mode
