Attributes
Description
type
The 10G XFP multi-mode optical module transceiver supports two types of multi-mode
optical fibers with different cores. Table 6-563 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type.If this type of optical fiber is
required, you need to purchase it additionally.
Table 6-563 The transmission distance of 10G XFP optical modules
Core (μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
Technical Specifications
Table 6-564 lists the technical specifications of the 4-Port 10GBase WAN/LAN-XFP Flexible
Card.
Table 6-564 Technical specifications of the 4-Port 10GBase WAN/LAN-XFP Flexible Card
Item
Specifications
Silkscreen of the board
name
4 x 10GBase LAN/WAN-XFP
Power consumption
(typical value)
About 34 W
Heat dissipation
110 BTU/hour
Board weight
About 1.5 kg ( 3.31 lb )
Dimensions (width x
depth x height)
345 mm x 185 mm x 41mm ( 13.58 in. x 7.28 in. x 1.61 in. )
Connector type
LC
Earliest software version
V600R001
Product Specifications
Table 6-565 lists the product specifications of the 4-Port 10GBase WAN/LAN-XFP Flexible
Card.
