Indicator
Description
LINK/ACT
indicator(green)
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-609 lists the interface attributes of the 4-port OC-12c/STM-4c POS-SFP FPIC.
Table 6-609 Interface attributes of the 4-port OC-12c/STM-4c POS-SFP FPIC
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected SFP optical module (for the attributes of SFP
modules, see Table 6-610)
Working mode
Full-duplex
Link protocol
PPP or HDLC
Network
protocol
IP
Table 6-610 Attributes of 622M SFP optical modules
Attributes
Description
Maximum
transmission
distance
15 km ( 9.32 mi. )
40 km ( 24.86 mi. )
80 km ( 49.71 mi. )
Center
wavelength
1310 nm
1310 nm
1550 nm
Minimum
transmitting
power
-15.0 dBm
-3.0 dBm
-3.0 dBm
Maximum
transmitting
power
-8 dBm
2.0 dBm
2.0 dBm
Receiving
sensitivity
-31.0 dBm
-30.0 dBm
-30.0 dBm
Overload
optical power
-8.0 dBm
-8.0 dBm
-8.0 dBm
Optical fiber
type
Single-mode
Single-mode
Single-mode
