HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
3 NE40E-X8 Chassis Overview
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
TYPE II
(compatible
with TYPE I)
It is used to hold a CF card to store data files
as a massive storage device.
CTL-ETH-SFP
interface
(1000MBase-X)
It is reserved for the use after capacity
expansion.
MGMT-ETH interface
(10M/100M/1000M
Base-TX auto-sensing)
It connects to the NMS workstation and has
LINK and ACT indicators.
It connects to the console for on-site
configuration of the system.
It connects to the Modem for remote
maintenance through dialing.
It is used to input or output 2-Mbit/s clock
signals, 2-MHz clock signals, 1pps+ASCII
clock signals, or 2-channel DCLS clock
signals.
It is used to input or output 2-Mbit/s clock
signals, 2-MHz clock signals, or 1 PPS signals.
It is used to input or output 2-Mbit/s clock
signals, 2-MHz clock signals, or RS232
signals.
Bits2 includes 2 SMB ports, and the signal type can be set as 2Mbps/2Mhz/1PPS+RS232. When signal
is 2Mbps/2Mhz, CLK/1PPS is fixed as input and CLK/Serial is fixed as output. When signal is
1PPS+RS232, CLK/1PPS and CLK/Serial are bound together, CLK/1PPS signal type is 1PPS whereas
CLK/Serial signal type is RS232, and the setting of input/output apply to both SMB ports.
Interface Attributes
Table 3-29 lists the 1000MBase-X-SFP interface attributes.
Table 3-29 1000MBase-X-SFP interface attributes
Single-mode or multi-mode fibers
