[SwitchE-mst-region] active region-configuration
[SwitchE-mst-region] quit
Step 2 Create RRPP domains and configure the control VLANs and protected VLANs of the domains.
# Configure domain 1 on Switch E, which is the master node of ring 1. Configure VLAN 10 as
the main control VLAN of domain 1, and configure the list of protected VLANs mapping
instance 1.
[SwitchE] rrpp domain 1
[SwitchE-rrpp-domain-region1] control-vlan 10
[SwitchE-rrpp-domain-region1] protected-vlan reference-instance 1
[SwitchE-rrpp-domain-region1] quit
# Configure domain 1 on Switch C, which is the transit node of ring 1. Configure VLAN 10 as
the main control VLAN of domain 1, and configure the list of protected VLANs mapping
instance 1.
[SwitchC] rrpp domain 1
[SwitchC-rrpp-domain-region1] control-vlan 10
[SwitchC-rrpp-domain-region1] protected-vlan reference-instance 1
[SwitchC-rrpp-domain-region1] quit
# Configure domain 1 on Switch D, which is the transit node of ring 1. Configure VLAN 10 as
the main control VLAN of domain 1, and configure the list of protected VLANs of instance 1.
[SwitchD] rrpp domain 1
[SwitchD-rrpp-domain-region1] control-vlan 10
[SwitchD-rrpp-domain-region1] protected-vlan reference-instance 1
[SwitchD-rrpp-domain-region1] quit
# Configure domain 2 on Switch E, which is the master node of ring 2. Configure VLAN 20 as
the main control VLAN of domain 2, and configure the list of protected VLANs mapping
instance 1.
[SwitchA] rrpp domain 2
[SwitchA-rrpp-domain-region2] control-vlan 20
[SwitchA-rrpp-domain-region2] protected-vlan reference-instance 2
[SwitchA-rrpp-domain-region2] quit
# Configure domain 2 on Switch B, which is the transit node of ring 2. Configure VLAN 20 as
the main control VLAN of domain 2, and configure the list of protected VLANs of instance 2.
[SwitchB] rrpp domain 2
[SwitchB-rrpp-domain-region2] control-vlan 20
[SwitchB-rrpp-domain-region2] protected-vlan reference-instance 2
[SwitchB-rrpp-domain-region2] quit
# Configure domain 2 on Switch C, which is the transit node of ring 2. Configure VLAN 20 as
the main control VLAN of domain 2, and configure the list of protected VLANs of instance 2.
[SwitchC] rrpp domain 2
[SwitchC-rrpp-domain-region2] control-vlan 20
[SwitchC-rrpp-domain-region2] protected-vlan reference-instance 2
[SwitchC-rrpp-domain-region2] quit
Step 3 Set the timers of the RRPP domains
NOTE
You can set two timers for the tangent point because the two tangent rings reside in different domains.
# Set the Hold timer and Fail timer for Switch E, the master node on ring 1.
[SwitchE] rrpp domain 1
[SwitchE-rrpp-domain-region1] timer hello-timer 2 fail-timer 7
[SwitchE-rrpp-domain-region1] quit
Quidway S6700 Series Ethernet Switches
Configuration Guide - Reliability 3 RRPP Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
90
