92
[Combination Example 2] When number of Simple Direct Mode/Positioner 1 Mode axes is
6 and number of Direct Indication Mode 2
CC-Link: (Extended Cyclic Setting/Number of Occupied
Stations: 8 times/2 stations)
PLC → MCON MCON → PLC
Address Description Address Description
RY 000 to 01F Gateway Control RX 000 to 01F Gateway Status
RY 020 to 06F Demand Command RX 020 to 06F Response Command
RY 070 to 07F Cannot be used. RX 070 to 07F Cannot be used.
RY 080 to 17F Cannot be used. RX 080 to 17F Cannot be used.
RWw 00 to 03
Axis No.0 Control
Information
RWr 00 to 03
Axis No.0 Status
Information
RWw 04 to 07
Axis No.1 Control
Information
RWr 04 to 07
Axis No.1 Status
Information
RWw 08 to 0B
Axis No.2 Control
Information
RWr 08 to 0B
Axis No.2 Status
Information
RWw 0C to 0F
Axis No.3 Control
Information
RWr 0C to 0F
Axis No.3 Status
Information
RWw 10 to 13
Axis No.4 Control
Information
RWr 10 to 13
Axis No.4 Status
Information
RWw 14 to 17
Axis No.5 Control
Information
RWr 14 to 17
Axis No.5 Status
Information
RWw 18 to 1B RWr 18 to 1B
RWw 1C to 1F
Axis No.6 Control
Information
RWr 1C to 1F
Axis No.6 Status
Information
RWw 20 to 23 RWr 20 to 23
RWw 24 to 27
Axis No.7 Control
Information
RWr 24 to 27
Axis No.7 Status
Information
RWw 28 to 2B Cannot be used. RWr 28 to 2B Cannot be used.
RWw 2C to 2F Cannot be used. RWr 2C to 2F Cannot be used.
RWw 30 to 33 Cannot be used. RWr 30 to 33 Cannot be used.
RWw 34 to 37 Cannot be used. RWr 34 to 37 Cannot be used.
RWw 38 to 3B Cannot be used. RWr 38 to 3B Cannot be used.
RWw 3C to 3F Cannot be used. RWr 3C to 3F Cannot be used.
* There is no domain prepared in CC-Link IE Field for the line shaded in .
3.4 Fieldbus Type Address Map
