IAI MCON-C - Page 166

156
20) Reading of Alarm-issued Axis Pattern [4000h]
PLC Output (Address n is the input and output top address for MCON Gateway Unit.)
Note If this command is sent, the response command updates with the latest
information until the demand command clear is sent.
Bit
Address b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
n+2
Demand
Command
[4000h]
0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+3
Data 0
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+4
Data 1
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+5
Data 2
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reading of Alarm-issued Axis Pattern
n+6
Data 3
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PLC Input (Address n is the input and output top address for MCON Gateway Unit.)
Bit
Address
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
n+2
Response
Command
[4000h]
0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+3
Data 0
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+4
Data 1
[Alarm-issued
Axis Pattern]
1: Alarm
2: Normal
– – – – – – – –
Status of
8th Axis
Status of
7th Axis
Status of
6th Axis
Status of
5th Axis
Status of
4th Axis
Status of
3rd Axis
Status of
2nd Axis
Status of
1st Axis
n+5
Data 2
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reading of Alarm-issued Axis Pattern
n+6
Data 3
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 word=16 bit
1 word=16 bit
3.4 Fieldbus Type Address Map
