157
21) Reading of Alarm Code [4001h]
PLC Output (Address n is the input and output top address for MCON Gateway Unit.)
Note If this command is sent, the response command updates with the latest information
until the demand command clear is sent.
Bit
Address b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
n+2
Demand
Command
[4001h]
0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 1
n+3
Data 0
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+4
Data 1
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+5
Data 2
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reading of Alarm Code
n+6
Data 3
[Axis No.]
–
–
–
–
–
–
–
–
–
–
–
–
–
4
2
1
PLC Input (Address n is the input and output top address for MCON Gateway Unit.)
Bit
Address
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
n+2
Response
Command
[4001h]
0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 1
n+3
Data 0
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
n+4
Data 1
[Alarm Code]
n+5
Data 2
[0]
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Reading of Alarm Code
n+6
Data 3
[Axis No.]
–
–
–
–
–
–
–
–
–
–
–
–
–
4
2
1
1 word=16 bit
1 word=16 bit
3.4 Fieldbus Type Address Map
To Next Page
