85
◎ In the case of CC-Link
Station Type: Ver.2.00 Remote device station
Extended Cyclic Setting/Occupied Station Number Setting:
Register the information of the occupations displayed on Gateway Parameter Setting Tool to
the master unit. Connection cannot be established if information other than occupation is
set. [Refer to 3.2.1 Operation Mode Setting]
Caution: ● Remote I/O Mode cannot be used together with other modes.
● Only Positioner 3 Mode and Remote I/O Mode are available to be selected in
CompoNet. (CompoNet occupies 32 bytes no matter of the number of axes.)
3.4 Fieldbus Type Address Map
