iSeries Model 250 Packages and AS/400e Server 250

AS/400e Server 250

The Model 250 System Unit is a PCI only based unit. It has a base

configuration of:

• Processor (one must be specified):

V4R5 is required for the following processors. Processor

performance CPW is provided.

– #2295 processor (50/15 CPW) with 256M memory

(2x CCIN 3022)

– #2296 processor (75/20 CPW) with 256M memory

(2x CCIN 3022)

Performance figures shown are for the client/server and

interactive in an unconstrained environment. Memory and disk I/O

constraints may limit the performance of some applications.

• Multifunction I/O Processor (MFIOP CCIN 6757)

Both the processor and MFIOP are combined onto one card. The base disk controller

(CCIN 9728) is embedded. Feature #9728 is not required.

• Base DASD/Tape Cage with support for four internal disk units, one internal tape, and

one internal CD-ROM

• One 8.58 GB Disk Unit

• #9771 Base PCI 2-Line WAN with Modem

• One CD-ROM unit (CCIN 6321)

• One Console attachment (choose one of the following options):

– #9720 Twinaxial/WAN IOA option for Twinaxial Console and ECS

– LAN Adapter option: Select one of the following LAN features plus #0398 Operations

Console package:

• #9723 Base Ethernet IOA

• #9724 Base PCI Token-Ring IOA

• #9738 Base PCI 100/10 Ethernet IOA

Note: The #0398 is not included in the base system. It is a required priced

feature with the base LAN option. This special package is for the Model 250 only

and includes CCIN 2745 and CCIN 0367.

Note: When the #2746 is on the order, the #0398 is not required with the base

LAN option.

AS/400e Server 250

System Unit
