iSeries Model 250 Packages and AS/400e Server 250
94 iSeries Handbook
• Six PCI card slots
• The following software products are always preloaded and included with the Model 250
base system:
– 5769-SS1 OS/400
– 5769-QU1 Query
– 5769-ST1 DB2 Query manager and SQL development kit for AS/400
– 5769-XW1 AS/400 Client Access Family for Windows
A new processor group, PPS (processor-based packaged software), supports these four
programs only when ordered as part of this package. Processor-based programs, other
than these four, are charged at the P05 group when ordered for a Model 250.
The AS/400e Model 250 servers are Customer Setup (CSU).
OS/400 V4R5 is required to support the 250 servers.
iSeries Model 250 Packages
Two package offerings are available for the iSeries Model 250. The packages correspond to
the AS/400e Server 250 processors but provide specific configurations when ordered from
IBM. The defined hardware configurations cannot be modified when ordered, but additional
features supported by the Model 250 may be added later through an IBM Business Partner.
The two packages are:
• #0297 Entry Package (CCIN 2295, 50/15 CPW)
• #0298 Growth Package (CCIN 2296, 75/20 CPW)
Performance figures shown are for the client/server and interactive in an unconstrained
environment. Memory and disk I/O constraints may limit the performance of some
applications.
Both packages offer the following features:
• 256 MB of Memory (CCIN 3002)
• Multifunction I/O Processor (MFIOP CCIN 6757)
Both the processor and MFIOP are combined onto one card. The base disk controller
(CCIN 9728) is embedded. Feature #9728 is not required.
• Base DASD/Tape Cage with support for four internal disk units, one internal tape, and
one internal CD-ROM
• Two #6718 17.54 GB 10K RPM Disk Units with Disk Level Mirroring (#0040) activated
• #9771 Base PCI 2-Line WAN with Modem
• One CD-ROM unit (CCIN 6321)
