iSeries Model 830
170 iSeries Handbook
Main Storage
All main storage on the Model 830 is feature main storage. All main storage DIMMs on the
Model 830 must be added in sets of eight (octals) of the same capacity and technology. Note
that the #3065 and #3066 cannot be mixed in the same octal. There are a total of 64 DIMM
slots available on the Model 830. Of the 64 slots, 32 are “base”, and an additional 32 are
available with feature #2881 Main Storage Expansion installed.
These memory features are available on the Model 830:
• #3000: Migrated 128 MB Main Storage DIMM—
Support only
– Available only on upgrades from Models 620/S20/720 to the Model 830
– Only a quantity of two is supported
– Supported in octal(s) with #3062
• #3062: 128 MB Main Storage DIMM
• #3064: 256 MB Main Storage DIMM
• #3065: 512 MB Main Storage DIMM (128 Mb technology)
• #3066: 512 MB Main Storage DIMM (256 Mb technology)
• #3067: 1 GB Main Storage DIMM (256 Mb technology) requires V5R1
For processors #2400 and #2402:
• For new systems without #2881 Main Storage Expansion, DIMMs are added in octals
on the base Main Storage card.
• For new systems with #2881 Main Storage Expansion, DIMMs are added in octals and
“spread” across the Base Main Storage card (CCIN 2881) and the #2881 Main Storage
Expansion.
• For MES orders without #2881 Main Storage Expansion, DIMMs are added in octals
on the Base Main Storage card (CCIN 2881).
• For MES orders with #2881 Main Storage Expansion, DIMMs are added in octals and
“spread” across the Base Main Storage card and the #2881 Main Storage Expansion.
• If a #2881 Main Storage Expansion is added on an MES order, it is not required that
the DIMMs (in octals) are “spread” equally between the Base Main Storage card
(CCIN 2881) and the #2881 Main Storage Expansion.
#2403
#1531 #23D8 P40
#1532 #23D9 P50
#1533 #23DA P50
#1534 #23DB P50
#1535 #23DC P50
#1536 #23DD P50
#1537 #23DE P50
