iSeries Model 250 Packages and AS/400e Server 250
102 iSeries Handbook
• Frame Relay protocol
• IPX protocol
• X.25 with more than 16 virtual circuits per line
• SDLC protocol if used to connect to more than 64 remote sites
• Communications line speeds greater than 64 Kbps and up to 2.048 Mbps for the SDLC
or Frame Relay protocols (Bisync is always limited to a maximum of 64 Kbps)
• Asynchronous communications or Asynchronous PPP line speeds greater than 115.2
Kbps
• Non-Asynchronous Communications line speeds greater than 64 Kbps and up to 640
Kbps for X.25
• No high speed communication line allowed when a feature code #2750, #2751, or
#2761 is installed under the same IOP
• V.25 Autocall cable not supported
• Select standby mode not supported
In particular, this applies when using #2745 PCI Two-Line WAN IOA or the IPX protocol (IPX
is used over LAN, ATM, or frame relay).
Rules for individual communication cards (adapters or processors) are found with an
explanation of the applicable feature description in the
iSeries and AS400e System Builder
,
SG24-2155.
For further considerations and sizing rules, refer to the feature descriptions of the specific
adapters or IOPs in the Model 250 chapter of the
iSeries and AS400e System Builder
,
SG24-2155, and the iSeries Information Center at
http://publib.boulder.ibm.com/pubs/html
Select
Information Center->your language of choice->What’s New.
For general communications performance considerations, refer to the online-document
AS/400 Performance Capabilities
, SC41-0607. It is available in softcopy only by visiting the
Web site at
http://publib.boulder.ibm.com/pubs/html/
Select
Online Library->your language of choice->What’s New.
Encryption
#4801 PCI Crypto Coprocessor
The #4801 is a hardware cryptography solution. The #4801 is a half-length PC form-factor
PCI card which offers rich cryptography function, secure storage of cryptographic keys, and
