Towers and Racks 245

Towers and Racks

#5111 30-Disk Expansion With Dual Line Cord Feature

The #5111 is a disk unit expansion enclosure for systems and towers that are dual line cord

enabled. It includes two 15 disk unit enclosures, backplanes, and cables. Two #4748/#4778

PCI RAID Disk Unit Controllers are required to support 30 disk units.

Prerequisites:

• #5103 when ordered for a Model 830 system unit

• #5104 when ordered for a Model 840 system unit

• #5105 when ordered for a stand alone #5074 I/O Tower or the top unit in a #8079

• #5106 for the unit in a #5079 where this expansion enclosure will be installed

OS/400 V5R1 and supporting PTFs are required. Refer to Informational APAR II12950 at:

http://as400service.rochester.ibm.com/supporthome.nsf/document/10000035
