Towers and Racks
254 iSeries Handbook
#5106 Dual Line Cord - I/O Tower
The #5106 provides dual line cord capability for a single unit in a #5079 1.8m PCI I/O
Expansion Tower. Two 14XX line cords are required for each #5106 on an initial order for a
#5079. When ordering a #5106 alone as an MES for an installed #5079, one additional 14XX
line cord is required for each #5106 ordered.
Prerequisite: If the #5079 has any feature #5101 (30-Disk Expansion Feature) installed, the
#5101 must be converted to a #5111.
OS/400 V5R1 plus PTFs, or later is required. Refer to Informational APAR II12950 at:
http://as400service.rochester.ibm.com/supporthome.nsf/document/10000035
e-configurator users can refer to this Web site for ordering information:
http://w3-1.ibm.com/sales/systems/ibmsm.nsf/MainFrameset?OpenForm&cdoc=idlcinstall
Migration Towers
Migration Towers are the result of an upgrade from a AS/400e 6xx, 7xx, or Sxx model to an
iSeries server Model 8xx. All the I/O and Disk Units in the former system unit and any
attached towers remains accessible to the upgraded system through the connection of the
Migration Tower to the HSL Loop. Migration Towers are not supported by the Model 270. One
Migration Tower is supported on each Model 8xx.
Configuration rules for towers are fully described in Chapter 4 “Migration rules” of the
redbook
AS/4003 to iSeries Migration
, SG24-6055.
#5033 Migration Tower I (600/S10 System Unit)
The #5033 is a converted 600/S10 system unit/CEC tower used for
migrating existing PCI cards, existing disk units, and existing
removable media devices. Additional “pre-V4R5” features may be
ordered to use vacant card/device slots in this tower. “V4R5 only”
feature cards and internal devices are not allowed in this tower.
This feature is for upgrade migration purposes only. It cannot be
ordered separately.
The #5033 can only attach to Models 820 and 830. There is a
maximum of one #5033 on a Model 820 and 830.
Select any two of the following HSL cable features for this tower:
• #1460 - 3m Copper HSL cable
• #1461 - 6m Copper HSL cable
• #1462 - 15m Copper HSL cable
#5033 Migration Tower 1
