iSeries Model 250 Packages and AS/400e Server 250
98 iSeries Handbook
Note:
The #2720 PCI WAN/Twinaxial IOA can be ordered manually to change the console
from Operations Console. The administrative sales records should be RPOed to show a
#9720 Base PCI WAN/Twinaxial IOA installed.
Multifunction I/O Processor (MFIOP)
A base MFIOP is standard on all Model 250s.
Note: Other IOP cards support several functions. Therefore, the term MFIOP is not limited to
designate the base MFIOP as on earlier models.
PCI Base Multifunction IOP
This MFIOP provides support for two low-speed PCI card slots and one high-speed PCI card
slot. It also drives one additional card, which is either an Integrated xSeries Server or an
additional high-speed slot.
Low-speed PCI Slot (C09) Supports the base #9771 Base PCI 2-Line WAN with Modem,
#2745 PCI 2-Line WAN IOA, #2746 PCI Twinaxial Workstation
IOA, or #9720 PCI WAN/Twinaxial IOA. C09 can also support
a #2723/#9723 PCI Ethernet IOA or #2724/#9724 PCI
Token-Ring IOA if C03 does not contain a #2838 100/10 Mbps
Ethernet IOA.
Low-speed PCI slot (C08) Supports #0398 Operations Console Package (CCIN 2745
and CCIN 0367) or #9720 PCI WAN/Twinaxial IOA or #9771
Base PCI 2-Line WAN with Modem
High-speed slot (C07) Supports #2763 PCI RAID Disk Unit controller or #2748 PCI
RAID Disk Unit Controller.
High-speed slot (C03) If no #2866 Integrated Netfinity Server is installed in slots
C02/C04, then C03 may be used for a #2723/#9723 PCI
Ethernet IOA, #2724/#9724 PCI Token-Ring IOA,
#2838/#9738 100/10 Mbps Ethernet IOA, #2750, #2751, or
#2761 Integrated Analog Modem.
Reserved Slots (C02/C04) The MFIOP supports #2866 Integrated NetfinityServer in slots
C02/C04 only if no card is installed in high-speed slot C03.
Notes: The Base PCI Disk controller (CCIN 9728) is embedded on the backplane.
#2824 PCI LAN/WAN/Workstation IOP
The #2824 PCI IOP is a feature I/O processor with 32 MB of controller memory. The #2824 is
installed in the #7102 System Expansion Unit. The #7102 has a base controller (CCIN 2824)
in slot E10.
