I/O Processor
280 iSeries Handbook
#2790 PCI Integrated Netfinity Server
#2791 Integrated xSeries Server
The #2790 PCI Integrated Netfinity Server contains a 700 MHz slot 1 processor and four
memory slots in the Netfinity IOP.
The #2791 Integrated xSeries Server contains an 850 MHz Socket 370 processor and four
memory slots in the Netfinity IOP.
The #2790/#2791 is supported in the CEC of Models 820, 830, 840, SB2, and SB3, in the
#5074 PCI Expansion Tower, in the #5078 PCI Expansion Unit, in the #5079 1.8m PCI I/O
Expansion Tower, and in the #5075 PCI Expansion Tower when it is attached to the Model
820.
Each memory slot can contain either a 128 MB, a 256 MB, or a 1024 MB Netfinity IOP
Memory card. This provides a total memory capacity ranging from 128 MB to 4 GB.
Note: When the maximum memory is installed, only 3712 MB will be addressable.
At least one memory card in the Netfinity IOP is required.
The feature numbers of the Netfinity IOP memory cards are:
• #2795 - 128 MB Netfinity IOP Memory
• #2796 - 256 MB Netfinity IOP Memory
• #2797 - 1 GB Netfinity IOP Memory
At least one LAN IOA is required. Refer to the “PCI Card Placement Rules” chapter of the
iSeries and AS/400e System Builder
, SG24-2155, for details and limitations.
The #2790/#2791 supports up to three, in any combination, of these LAN IOA features:
• #2743 PCI 1Gbps Ethernet IOA
• #2760 PCI 1Gbps Ethernet UTP IOA
• #4838 PCI 100/10 Mbps Ethernet IOA
• #2744 PCI 100 Mbps Token-Ring IOA
Allowable Main Storage Increments (MB)
128 256 384 512 640 768 896 1024
1152 1280 1408 1536 1664 1792 2048
2176 2304 2432 2560 3072
3200 3328 4096
