I/O Adapters and Controllers
308 iSeries Handbook
If the #2723/#9723 is selected to run on a #2866 Integrated Netfinity Server, one #0221
(Ethernet on Integrated Netfinity Server) is required for each #2723/#9723 this is ordered.
#2724/#9724 PCI 16/4 Mbps Token-Ring IOA
This feature provides a single attachment to either a 16 Mbps or 4 Mbps token-ring. The
feature consists of an IOA card, internal code, which supplies IEEE 802.5 Media Access
Control (MAC), and IEEE 802.2 Logical Link Control (LCC) functions. The IOA is capable of
operating in half or full duplex mode.
The #2724/#9724 comes standard with an 8ft/2.44m token-ring cable. An alternately or a
separately purchased twisted-pair cable to the RJ-45 connection on the IOA may be
attached.
The #2724/#9724 provides one LAN attachment for the #6618 Integrated Netfinity Server.
The #6618 is a prerequisite for the #2724/#9724, and it uses one LAN IOA slot in the #6618.
If the #2724/#9724 is selected to run on a #2866 Integrated Netfinity Server, one #0220
(token-ring on Integrated Netfinity Server) is required for each #2724/#9724 ordered.
#2745/9745 PCI Two-Line WAN IOA
Supports up to two multiple protocol communications ports when one or two (in any
combination) of these cables are attached:
• #0348 V.24/EIA232 20ft/6m PCI cable
• #0349 V.24/EIA232 50ft/15m PCI cable
• #0353 V.35 20ft/6m PCI cable
• #0354 V.35 50ft/15m PCI cable
• #0355 V.35 80ft/24m PCI cable
• #0356 V.36 20ft/6m PCI cable
• #0358 V.36 150ft/45m PCI cable
• #0359 X.21 20ft/6m PCI cable
• #0360 X.21 50ft/15m PCI cable
• #0365 V.24/EIA232 80ft/24m PCI cable
• #0367 Operations Console cable*
*Only one #0367/#9745 Operations Console cable is allowed per #2745.
#2746 PCI Twinaxial Workstation IOA
The #2746 is an 8-port twinaxial workstation IOA with a 20-foot attachment cable for
attaching up to 40 5250-type displays and printers. Each port supports seven attached
addresses and allows up to 56 attached addresses of which only 40 can be active. When the
attached display supports address sharing, a maximum of 120 shared sessions are
supported. The #2746 is specified when additional PCI twinaxial workstation controllers are
