iSeries Model SB2 229
iSeries Model SB2
The 11 PCI IOAs are supported (driven) by the base #9943 PCI IOP and by feature #2843
PCI IOPs or feature #2791 Integrated xSeries Servers.
The #9074 also supports up to two removable media devices (internal tape or
CD-ROM/DVD-RAM), which are supported by the #9778.
The Model SB2 is based on the Model 830. For system diagrams, see “iSeries Model 830” on
page 165.
I/O Processor and I/O Adapter Support
This section lists the supported IOPs and IOAs. See “I/O Processor” on page 277 and “I/O
Adapters and Controllers” on page 291 for full descriptions.
LAN/WAN/Workstation IOAs
• #2743 PCI 1 Gbps Ethernet IOA
• #2744 PCI 100 Mbps Token Ring IOA
• #2760 PCI 1Gbps Ethernet UTP IOA
• #2772 Dual WAN/Modem IOA
• #2773 Dual WAN/Modem IOA
• #2723 PCI 10 Mbps Ethernet IOA
• #2817 PCI 155 Mbps MMF ATM IOA
• #4745 PCI Two Line WAN IOA
• #4746 PCI Twinaxial IOA
• #4750 PCI ISDN BRI U IOA
• #4751 PCI ISDN BRI S/T IOA
• #4761 PCI Integrated Analog Modem
• #4801 PCI Cryptographic Coprocessor
• #4815 PCI 155 Mbps UTP OC3 ATM IOA
• #4816 PCI 155 Mbps MMF ATM IOA
• #4818 PCI 155 Mbps SMF ATM IOA
• #4838 PCI 100/10 Mbps Ethernet IOA
• #9771 Base PCI 2-Line WAN with Modem
PCI configuration rules for V5R1 hardware are quite flexible. See the “PCI Card Placement
Rules” chapter of the
iSeries and AS/400e System Builder
, SG24-2155, for rules for
placing PCI card in configurations.
Note
