iSeries Model SB3

240 iSeries Handbook

Internal Disk Units

• #4317 8.58 GB 10k RPM Disk Unit

• #4318 17.54 GB 10k RPM Disk Unit

• #4331 1.6 GB Read Cache Device

Internal Tape, CD-ROM, and DVD-RAM

• #4425 CD-ROM

• #4430 DVD-RAM

• #4482 4 GB ¼-inch Cartridge Tape

• #4483 16 GB ¼-inch Cartridge Tape

• #4486 25 GB ¼-inch Cartridge Tape

• #4487 50 GB ¼-inch Cartridge Tape

External Towers

The #5077 Migration Tower II attaches to the Model SB3 via HSL (High Speed Link). See

“Expansion Towers” on page 243 for full a description.
