Towers and Racks 255

Towers and Racks

Select one of these SPCN cables:

• #1463 - 2m SPCN cable

• #1464 - 6m SPCN cable

• #1465 - 15m SPCN cable

• #1466 - 30m SPCN cable

The existing system unit line cord should be used. Available line cord options are identified in

the

iSeries and AS400e System Builder

, SG24-2155.

The #5033 is mutually exclusive with #5034, #5035, and #5077.

Note: The #1462 15m HSL cable can only be used on HSL port A1 of the Model 820 to

directly connect a #5033 Migration Tower I.
