iSeries Model 250 Packages and AS/400e Server 250 107
iSeries Model 250 Packages and AS/400e Server 250
Notes:
1. No high-speed LAN is allowed in Slot C09.
2. If any LAN is in Slot C03, no LAN card is allowed in Slot C09.
3. A maximum of three LAN cards are allowed on the MFIOP (including Integrated Server
slots C05 and C06).
4. Communications cards #2750, #2751, and #2761 are
only allowed in high-speed Slot
C03.
9406 Model 250 System Unit and PCI Card Placement
OP Panel
340 Watt Power Supply
PROCESSOR
MFIOP
D02
D01
CD-ROM
Magnetic Media
Disk Unit
Disk Unit
Disk Unit
Disk Unit
L01
L02
L03
L04
Base Memory Base Memory
Memory DIMMs plug directly to the planar
and must be added in pairs.
Slot
C08
C09
C06
C07
C05
C04
C03
C02
PCI 2-Line WAN w/Modem #9771
WAN/Twinax IOA #9720 or
Operations Console Package #0398
Disk Controller #2763/#2748
Integrated Server LAN Slot
Integrated Server High Speed LAN Slot
Integrated Server Bridge Slot (reserved)
LAN / WAN slot
Integrated Server Proc Slot #2866
Embedded MFIOP
12
35
PCI Cards
4
7
8
