IBM i Series

Towers and Racks
250 iSeries Handbook
The #5078 includes two electrical cables to connect to a #5074/#9079 power source.
The 11 PCI IOAs are supported (driven) by feature #2843 PCI IOPs, feature #2790 Integrated
Netfinity Servers, or feature #2791/#2799 PCI Integrated xSeries Servers.
The #5078 can also be mounted in a #0550/#0551 iSeries Rack by ordering feature code
#0578 instead of #5078. See page 265 for information on the #0550, #0551, and #0578.
The #5078 PCI Expansion Unit counts as one tower for HSL loop rules.
#5078 PCI Expansion Unit
OP Panel
PCI Cards
Multi-Adapter Bridge Bus Number
Multi- Adapter Bridge Boundary
Multi- Adapter Bridge Boundary
C01 C02 C03 C04 C05 C06 C07 C09 C10 C11 C12 C13 C14 C15 Slots
3 IOA
4 IOA
1,2 IOP/Int. xSeries Svr.
5,6 IOP/IOA
HSL
7,8 IOA
3,4 IOA
5,6 IOP/IOA 7,8 IOA
1,2 IOP
5,6 IOP/IOA
4 IOA
1,2 IOP/Int. xSeries Svr.
7,8 IOA
3 IOA
1
2
Back
Legend
Base Feature
Required Feature
Unavailable if
Integrated xSeries
Server is installed
Note 1:
If C05 has an Integrated xSeries Server,
slot C06 is unavailable, and slot C07 is available
only as a short slot.
Note 2:
If C11 has an Integrated xSeries Server,
slot C12 is not available, and slot C13 is available
only as a short slot.
Front
BULK
B03
BULK
B04
