Towers and Racks
258 iSeries Handbook
The #5035 can only attach to Models 820 and 830. There is a maximum of one #5035 on a
Model 820 and 830.
Attaching additional PCI/SPD towers to the #5035 after migrating to the Model 820 is not
allowed.
Select any two of these HSL cable features for this tower:
• #1460 - 3m Copper HSL cable
• #1461 - 6m Copper HSL cable
• #1462 - 15m Copper HSL cable
Select one of these SPCN cables:
• #1463 - 2m SPCN cable
• #1464 - 6m SPCN cable
• #1465 - 15m SPCN cable
• #1466 - 30m SPCN cable
The existing system unit/CEC line cord should be used. Available line cord options are
identified in the
iSeries and AS400e System Builder
, SG24-2155.
The #5035 is mutually exclusive with #5033, #5034, and #5077.
Note: The #1462 15m HSL cable can only be used on HSL port A1 of the Model 820 to
directly connect a #5035 Migration Tower I.
