I/O Processor
282 iSeries Handbook
At least one Netfinity IOP memory card is required.
The feature numbers of the Netfinity IOP memory cards are:
• #2795 - 128 MB Netfinity IOP Memory
• #2796 - 256 MB Netfinity IOP Memory
• #2797 - 1 GB Netfinity IOP Memory
At least one LAN IOA is required. Refer to the “PCI Card Placement Rules” chapter of the
iSeries and AS/400e System Builder
, SG24-2155, for complete rules for placing these PCI
cards in configurations.
The #2890/#2891 supports up to three, in any combination, of these LAN IOA features:
• #2743 PCI 1 Gbps Ethernet IOA
• #2760 PCI 1 Gbps Ethernet UTP IOA
• #4838 PCI 100/10 Mbps Ethernet IOA
• #2744 PCI 100 Mbps Token-Ring IOA
One #0225 (1 Gbps Ethernet on the Integrated Netfinity Server) is required for each 1 Gbps
Ethernet adapter selected to run on the #2890/#2891.
One #0224 (100/10 Mbps Ethernet on the Integrated Netfinity Server) is required for each
#4838 selected to run on the #2890/#2891.
One #0223 (100 Mbps Token-Ring on the Integrated Netfinity Server) is required for each
#2744 selected to run on the #2890/#2891.
Native iSeries and AS/400e functions are not supported. The #2890/#2891servers do not
support external host LAN.
The #2890/#2891 requires two PCI card slots in the Model 270 system unit. One slot is
consumed, and the second slot is reduced to a short card slot, which is used by the first
attached LAN IOA card.
Allowable Main Storage Increments (MB)
128 256 384 512 640 768 896 1024
1152 1280 1408 1536 1664 1792 2048
2176 2304 2432 2560 3072
3200 3328 4096
