I/O Adapters and Controllers

306 iSeries Handbook

• 7207-Model 122 QIC-SLR Tape Bridge Box

• 7210-Model 020 CD-ROM Bridge Box

• 7210-Model 025 DVD-RAM drive

• 7329-308 SLR100 ¼-inch Tape Autoloader

• 7208-345 60 GB External 8mm Tape Drive

The #2768 PCI Magnetic Media Controller

supports one, or a combination, of these devices:

• One 7207- Model 122

• One 7210- Model 020

• One 7210- Model 025

• One 7329- Model 308

• One 7208-345

• One 7210- Model 025 and one 7210- Model 025 (the two devices are daisy-chained)

• One 7210- Model 025 and one 7210- Model 020 (the two devices are daisy-chained

with the 7210- Model 025 physically connected first; no #0120 attachment specify

code is required for the 7210- Model 020)

• One 7207- Model 122 and one 7210- Model 020 (the two devices are daisy-chained

with the 7207- Model 122 physically connected first; no #0120 attachment specify

code is required for the 7210- Model 020)

• One 7207- Model 122 and one 7210- Model 025 (the two devices are daisy-chained

with the 7207- Model 122 physically connected first)

• One 7208-345 and one 7210-020 (the two devices are daisy-chained with the

7208-345 physically connected first, no #0120 attachment specify code is required for

the 7210-020)

• One 7208-345 and one 7210-025 (the two devices are daisy-chained with the

7208-345 physically connected first)

The #0120 7210-020 Attachment Specify is required for each 7210-020 External CD-ROM

Drive to be connected directly (not daisy chained) to the system through a #2768.

Note: If the 7210-020 is to be daisy chained with another external device, this specify code

must not be present.

The #0162 Extended Single Ended Attach Specify is required when these devices are directly

attached (not second on a daisy-chained string) to an iSeries server via a #2768.

• 7329-308 SLR100 ¼-inch Tape Autoloader

• 7210-025 External DVD- RAM Drive
