Externally Attached Automated Libraries
388 iSeries Handbook
Only two model upgrades are supported. These are for the 3995 Model C24 to Model C26
and for the Model C44 to Model C46.
The iSeries and AS/400e direct attach 3995 C-Models (C40, C42, C44, C46, and C48) can
attach using these features:
• #2621 Removable Media Device Attachment support on OS/400 V3R2 only with a
maximum of four internal drives or less (for example, does not support the optional six
drive configurations available for the model C46 and the model C48).
Note: #2621 cannot be used to attach the 3995 on OS/400 V5R1.
• #6534 Magnetic Media Controller (SPD) when using OS/400 V4R2 or later
• #2729 PCI Magnetic Media Controller when using OS/400 V4R2 or later
• #2749 PCI Ultra Magnetic Media Controller when using OS/400 V4R5 or later
See “I/O Adapters and Controllers” on page 291 for a description of these controllers.
This OS/400 software is required to support 3995-C4x 8X optical drives:
• OS/400 V4R4 or V4R5
• OS/400 V4R3 with Group PTF SF99089 for 8X Support
• OS/400 V4R2 with Group PTF SF99088 for 8X Support
• OS/400 V3R2 with 5755-AS3 #1979 and PRPQ 5799-XBW #3520 with Group PTF
SF99079 for 8X Support
The iSeries and AS/400e Integrated File System provides UNIX-type access to optical files
through commands and APIs. It also provides workstation-to-iSeries and iSeries-to-iSeries
access to optical byte-stream files.
3995
Model
Capacity Number of
Drives
Attachment Number of Auto
Changer Grippers
GDisks
C40
C42
C44
C46
C48
C20
C22
C24
C26
C28
104
270
540
811
1341
104
270
540
811
1341
20
52
104
156
258
20
52
104
156
258
1-2
2
2 or 4
4 or 6
4 or 6
1-2
2
2 or 4
4 or 6
4 or 6
Direct
Direct
Direct
Direct
Direct
LAN
LAN
LAN
LAN
LAN
1
2
2
2
2
1
2
2
2
2
