IBM i Series Handbook

Referenced Lists 809
Referenced Lists
IOP workload and bus data traffic may need to be considered for tape, DASD, and LAN
subsystems.
Feature Function 270 820
1
830
1
840
1
SB2
1
SB3
1
Migration
Towers
#2624 Storage Device Controller SPD
2
xxxx x
#6501 Tape/Disk Device Control SPD x x x x x x
#6513 Internal Tape Device Control SPD x x x x
#6533 RAID Disk Unit Control Ultra (4M) Compression SPD x x x x
#6534 Magnetic Media Control SPD x x x x x x
#2718 PCI Magnetic Media Controller x x x x
#2726 RAID Disk Unit Control Ultra (4M) PCI
3
xx x
#2729 Magnetic Media Control PCI x x x x
#2740 RAID Disk Unit Control Ultra (4M) PCI x x x
#2741 RAID Disk Unit Control Ultra (4M) Compression PCI
3
xx x
#2748 PCI RAID Disk Unit Controller x x x x
#2749 PCI Ultra Magnetic Media Controller x x x x x
#2763 PCI RAID Disk Unit (10M) Controller x x x x x
#2768 PCI Magnetic Media Controller x x x x x
#4748 PCI RAID Disk Unit (26M) Controller x x x x x
#9728 Base Disk Unit Control Ultra PCI
3
xx x
#9748 Base PCI Disk Unit (26M) Controller x x x
#9767 Base PCI Disk Unit Controller x x
#6146
(on #2624) 9331-01X Diskette Controller SPD
3
xxx x
Notes:
1. SPD cards in 8xx and SBx models are only supported in migration towers and towers attached to these
migration towers via the SPD Bus.
2. #2624 can support internal tape and diskette devices only.
3. No longer available, but is supported during migrations to these systems.
4. Supported in the #5065 Storage/PCI Expansion Tower only.
None of the above magnetic media controllers are supported on the 9401 models.
