144 IBM z13s Technical Guide

The locations of the DCAs, AMDs, PCIe switch cards, and I/O feature cards in the PCIe I/O

drawer are shown in Figure 4-3.

Figure 4-3 PCIe I/O drawer

~311mm

Rear

Front







Domain 3

Domain 1

Domain 0 Domain 2

AMD

16 GBps PCIe switch card

560mm (max)

DCA
