Chapter 7. Software support 273

7.3.47 Open Systems Adapter for IBM zAware

The IBM zAware server requires connections to the graphical user interface (GUI) browser

and z/OS monitored clients. An OSA channel is the most logical choice for allowing GUI

browser connections to the server. By using this channel, users can view the analytical data

for the monitored clients through the IBM zAware GUI. For z/OS monitored clients that

connect an IBM zAware server, one of the following network options is supported:

򐂰 A client-provided data network that is provided through an OSA Ethernet channel.

򐂰 A HiperSockets subnetwork within the z13s.

򐂰 IEDN on the z13s to other CPC nodes in the ensemble. The z13s server also supports the

use of HiperSockets over the IEDN.

7.3.48 Open Systems Adapter for Ensemble

Five different OSA-Express5S and OSA-Express4S features are used to connect the z13s to

Unified Resource Manager, and other ensemble nodes. These connections are part of the

ensemble’s two private and secure internal networks.

For the intranode management network (INMN), use these features:

򐂰 OSA Express5S 1000BASE-T Ethernet, FC 0417

򐂰 OSA Express4S 1000BASE-T Ethernet, FC 0408

For the IEDN, use these features (CHPID type OSX):

򐂰 OSA-Express5S 10 Gigabit Ethernet (GbE) Long Reach (LR), FC 0415

򐂰 OSA-Express5S 10 Gigabit Ethernet (GbE) Short Reach (SR), FC 0416

򐂰 OSA-Express4S 10 Gigabit Ethernet (GbE) Long Reach (LR), FC 0406

򐂰 OSA-Express4S 10 Gigabit Ethernet (GbE) Short Reach (SR), FC 0407

Linux on z

Systems

OSD:
