Chapter 11. Hardware Management Console and Support Elements 393
11.2.3 New Support Elements
The SEs are no longer two notebooks in one z13s server. They are now two servers that are
installed at the top of the CPC frame. They are managed by the keyboard, pointing device,
and display that are mounted in the front of the tray of the CPC frame (where the SE
notebooks were in previous z Systems servers), as shown in Figure 11-4. The SEs have an
internal USB attached smart card reader to support Flash Express and Features on Demand
(FoD).
Figure 11-4 SEs location
11.2.4 New backup options for HMCs and primary SEs
This section provides a short description of the new backup options that are available for
HMC Version 2.13.1.
Backup of primary SEs or HMCs to an FTP server
With Driver 22 or later, you can perform a backup of primary SEs or HMCs to an FTP server.
The FTP server must be supplied by the customer. You can enable a secure FTP connection
to your server.
Support
Elements (x2)
Monitor +
Keyboard for SEs
System
Control Hubs
Front ViewRear View
Smart Card Reader
internal USB attached unit
to support Flash Express
and Feature on Demand.
Monitor and
keyboar d cable
plug location
Note: If you do a backup to an FTP server for a z13s or zBX Model 004 server, ensure that
you have set up a connection to the FTP server by using the Configure Backup Setting
task. If you have not set up a connection to the FTP server, a message appears that
prompts you to configure your FTP server.
