160 IBM z13s Technical Guide
4.8.2 FICON channels
The FICON Express16S, FICON Express8S, and FICON Express8 features conform to the
following architectures:
Fibre Connection (FICON)
High Performance FICON on z Systems (zHPF)
Fibre Channel Protocol (FCP)
They provide connectivity between any combination of servers, directors, switches, and
devices (control units, disks, tapes, and printers) in a SAN.
Each FICON Express16S or FICON Express8S feature occupies one I/O slot in the PCIe I/O
drawer. Each feature has two ports, each supporting an LC Duplex connector, with one
PCHID and one CHPID associated with each port.
0409 FICON Express8S LX 10 km LC Duplex 9 µm SM
0410 FICON Express8S SX LC Duplex 50, 62.5 µm MM
3325 FICON Express8 LX 10 km LC Duplex 9 µm SM
3326 FICON Express8 SX LC Duplex 50, 62.5 µm MM
0415 OSA-Express5S 10 GbE LR LC Duplex 9 µm SM
0416 OSA-Express5S 10 GbE SR LC Duplex 50, 62.5 µm MM
0413 OSA-Express5S GbE LX LC Duplex 9 µm SM
0414 OSA-Express5S GbE SX LC Duplex 50, 62.5 µm MM
0417 OSA-Express5S 1000BASE-T RJ-45 Category 5 UTP
c
0404 OSA-Express4S GbE LX LC Duplex 9 µm SM
0405 OSA-Express4S GbE SX LC Duplex 50, 62.5 µm MM
0406 OSA-Express4S 10 GbE LR LC Duplex 9 µm SM
0407 OSA-Express4S 10 GbE SR LC Duplex 50, 62.5 µm MM
0408 OSA-Express4S 1000BASE-T RJ-45 Category 5 UTP
0411 10GbE RoCE Express LC Duplex 50, 62.5 µm MM
0172 Integrated Coupling Adapter
(ICA SR)
MPO 50 µm MM OM4
(4.7 GHz-km)
d
0171 HCA3-O (12xIFB) MPO 50 µm MM OM3
(2 GHz-km)
0170 HCA3-O LR (1xIFB) LC Duplex 9 µm SM
a. SM is single-mode fiber.
b. MM is multimode fiber.
c. UTP is unshielded twisted pair. Consider using category 6 UTP for 1000 Mbps connections.
d. Or 50 µm MM OM3 (2 GHz-km), but OM4 is highly recommended.
Feature code Feature name Connector type Cable type
