472 IBM z13s Technical Guide
C.1 Channel options supported on z13s servers
For all optical links, the connector type is LC Duplex, except for the 12xInfiniBand (IFB) and
the Integrated Coupling Adapter (ICA SR) connection, which are established with multifiber
push-on (MPO) connectors. The MPO connector of the 12xIFB connection has one row of
12 fibers, and the MPO connector of the ICA connection has two rows of 12 fibers. The
electrical Ethernet cable for the Open Systems Adapter (OSA) connectivity is connected
through an RJ45 jack.
Table C-1 lists the attributes of the channel options that are supported on z13s servers.
Table C-1 z13s channel feature support
Channel feature Feature
codes
Bit rate
a
in Gbps
(or stated)
Cable type Maximum
unrepeated
distance
b
Ordering
information
Fiber Connection (FICON)
FICON Express16S 10KM LX 0418 4, 8, or 16 SM 9 µm 10 km
(6.2 miles)
New build
FICON Express16S SX 0419 4, 8, or 16 OM2, OM3 See
Table C-2 on
page 473.
New build
FICON Express8S 10KM LX 0409
2, 4, or 8 SM 9 µm
10 km
(6.2 miles)
New build
FICON Express8 10KM LX 3325 Carry forward
FICON Express8S SX 0410
2, 4, or 8
OM1, OM2,
OM3
See
Table C-2 on
page 473.
New build
FICON Express8 SX 3326 Carry forward
Open Systems Adapter (OSA)
OSA-Express5S 10 GbE LR 0415
10 SM 9 µm
10 km
(6.2 miles)
New build
OSA-Express4S 10 GbE LR 0406 Carry forward
OSA-Expess5S 10 GbE SR 0416
10
MM 62.5 µm
MM 50 µm
33 m (200)
82 m (500)
300 m (2000)
New build
OSA-Express4S 10 GbE SR 0407 Carry forward
OSA-Express5S GbE LX 0413
1.25 SM 9 µm 5 km
(3.1 miles)
New build
OSA-Express4S GbE LX 0404 Carry forward
OSA-Express5S GbE SX 0414
1.25
MM 62.5 µm
MM 50 µm
275 m (200)
550 m (500)
New build
OSA-Express4S GbE SX 0405 Carry forward
OSA-Express5S 1000BASE-T 0417 100 or
1000
Mbps Cat 5, Cat 6
unshielded
twisted pair
(UTP)
100 m
New build
OSA-Express4S 1000BASE-T 0408 10, 100, or
1000
Mbps
Carry forward
