Chapter 7. Software support 269
Operating system support is required to recognize and use the second port on the
OSA-Express5S Gigabit Ethernet feature. Table 7-39 lists the minimum support requirements
for OSA-Express5S Gigabit Ethernet LX and SX.
Table 7-39 Minimum support requirements for OSA-Express5S Gigabit Ethernet LX and SX
7.3.43 OSA-Express5S 1000BASE-T Ethernet
The OSA-Express5S 1000BASE-T Ethernet feature is installed exclusively in the PCIe I/O
drawer. Each feature has one PCIe adapter and two ports. The two ports share a CHPID,
which can be defined as OSC, OSD, OSE, OSM, or OSN. The ports can be defined as a
spanned channel, and can be shared among LPARs and across logical channel subsystems.
The OSM CHPID type was introduced with z196. For more information, see 7.3.49,
“Intranode management network” on page 274.
Each adapter can be configured in the following modes:
QDIO mode, with CHPID types OSD and OSN.
Non-QDIO mode, with CHPID type OSE.
Local 3270 emulation mode, including OSA-ICC, with CHPID type OSC.
OSA-ICC (OSC Channel) supports Secure Sockets Layer on z13s and z13 Driver 27
servers.
– Designed to improve security of console operations.
– Up to 48 secure sessions per CHPID (the overall maximum of 120 connections
unchanged).
Ensemble management, with CHPID type OSM for dynamic I/O only.
Operating system Support requirements
using two ports per CHPID
Support requirements
using one port per CHPID
z/OS OSD: z/OS V1R12 OSD: z/OS V1R12
z/VM OSD: z/VM V6R2 OSD: z/VM V6R2
z/VSE OSD: z/VSE V5R1 OSD: z/VSE V5R1
z/TPF OSD: z/TPF V1R1 OSD: z/TPF V1R1
IBM zAware OSD OSD
Linux on z Systems OSD: SUSE Linux Enterprise
Server 12, SUSE Linux Enterprise
Server 11, Red Hat RHEL 7, and
Red Hat RHEL 6
OSD: SUSE Linux Enterprise
Server 12, SUSE Linux Enterprise
Server 11, Red Hat RHEL 7, and
Red Hat RHEL 6
