166 IBM z13s Technical Guide
4.8.3 OSA-Express5S
The OSA-Express5S feature is exclusively in the PCIe I/O drawer. The following
OSA-Express5S features can be installed on z13s servers:
򐂰 OSA-Express5S 10 Gigabit Ethernet LR, FC 0415
򐂰 OSA-Express5S 10 Gigabit Ethernet SR, FC 0416
򐂰 OSA-Express5S Gigabit Ethernet LX, FC 0413
򐂰 OSA-Express5S Gigabit Ethernet SX, FC 0414
򐂰 OSA-Express5S 1000BASE-T Ethernet, FC 0417
Table 4-10 lists the OSA-Express5S features.
Table 4-10 OSA-Express5S features
OSA-Express5S 10 Gigabit Ethernet LR (FC 0415)
The OSA-Express5S 10 Gigabit Ethernet (GbE) Long Reach (LR) feature has one PCIe
adapter and one port per feature. The port supports CHPID types OSD and OSX. When
FICON Express8 SX 3326 8 Gbps MM 62.5 µm
MM 50 µm
21 m (200)
50 m (500)
150 m (2000)
190 m (4700)
4 Gbps MM 62.5 µm
MM 50 µm
70 m (200)
150 m (500)
380 m (2000)
400 m (4700)
2 Gbps MM 62.5 µm
MM 50 µm
150 m (200)
300 m (500)
500 m (2000)
N/A (4700)
a. Minimum fiber bandwidths in MHz/km for multimode fiber optic links are included in parentheses where
applicable.
Channel feature Feature codes Bit rate Cable type Maximum unrepeated distance
a
(MHz - km)
I/O feature Feature
code
Number of
ports per
feature
Port
increment
Maximum
number of
ports
Maximum
number of
features
CHPID
type
OSA-Express5S
10 GbE LR
0415 1 1 48 48 OSD,
OSX
OSA-Express5S
10 GbE SR
0416 1 1 48 48 OSD,
OSX
OSA-Express5S
GbE LX
0413 2 2 96 48 OSD
OSA-Express5S
GbE SX
0414 2 2 96 48 OSD
OSA-Express5S
1000BASE-T
0417 2 2 96 48 OSC,
OSD,
OSE,
OSM,
OSN
