326 IBM z13s Technical Guide
Figure 8-4 shows the memory configurations and upgrades for a z13s Model N20 single CPC
drawer.
Figure 8-4 Memory sizes and upgrades for the single drawer N20
Figure 8-5 shows the memory configurations and upgrades for a z13s Model N20 with two
CPC drawers.
Figure 8-5 Memory sizes and upgrades for the two drawer N20
N20 one drawer
Physical Memory RAIM GB
Addressable Memory GB
Client
GB
Increment
GB
32 RAIM (2 x 16GB) +
128 for HSA (40) + Client (88)
64
72
80
88
8
64 RAIM (4 x 16GB) +
256 for HSA (40) + Client (216)
120
152
184
216
32
128 RAIM (4 x 32GB) +
384 for HSA (40) + Client (344)
248
280
312
344
32
128 RAIM (4 x 32GB) +
512 for HSA (40) + Client (472)
408
472
64
256 RAIM (4 x 64GB) +
640 for HSA (40) + Client (600)
536
600
64
256 RAIM (4 x 64GB) +
1024 for HSA (40) + Client (984)
728
856
984
128
512 RAIM (4 x 128GB) +
2048 for HSA (40) + Client (2008)
1112
1240
1368
1496
1624
1752
1880
2008
128
N20 two drawers
Physical Memory RAIM GB
Addressable Memory GB
Client
GB
Increment
GB
576 RAIM (4 x 128GB + 4 x 16GB)+
2304 for HSA (40) + Client (2264)
2264 256
640 RAIM (4 x 128 GB + 4 x 32GB)+
2560 for HSA (40) + Client (2520)
2520 256
768 RAIM (4 x 128GB + 4 x 64GB)+
3072 for HSA (40) + Client (3032)
2776
3032
256
1024 RAIM (8 x 128GB)+
4096 for HSA (40) + Client (4056)
3288
3544
3800
4056
256
