Chapter 7. Software support 271
Table 7-41 lists the minimum support requirements for OSA-Express4S 10-Gigabit Ethernet
LR and SR features.
Table 7-41 Minimum support requirements for OSA-Express4S 10-Gigabit Ethernet LR and SR
7.3.45 OSA-Express4S Gigabit Ethernet LX and SX
The OSA-Express4S Gigabit Ethernet feature is installed exclusively in the PCIe I/O drawer.
Each feature has one PCIe adapter and two ports. The two ports share a channel path
identifier (CHPID type OSD exclusively). Each port supports attachment to a 1 Gbps Ethernet
LAN. The ports can be defined as a spanned channel, and can be shared among LPARs and
across logical channel subsystems.
Operating system support is required to recognize and use the second port on the
OSA-Express4S Gigabit Ethernet feature. Table 7-42 lists the minimum support requirements
for OSA-Express4S Gigabit Ethernet LX and SX.
Table 7-42 Minimum support requirements for OSA-Express4S Gigabit Ethernet LX and SX
Operating system Support requirements
z/OS OSD: z/OS V1R12
a
OSX: z/OS V1R12
a
a. PTFs are required.
z/VM OSD: z/VM V6R2
OSX: z/VM V6R2
a
and V6R3 for dynamic I/O only
z/VSE OSD: z/VSE V5R1
OSX: z/VSE V5R1
z/TPF OSD: z/TPF V1R1
OSX: z/TPF V1R1
IBM zAware OSD
OSX
Linux on z Systems OSD:
SUSE Linux Enterprise Server 12
SUSE Linux Enterprise Server 11
Red Hat RHEL 7
Red Hat RHEL 6
OSX: SUSE Linux Enterprise Server 12
SUSE Linux Enterprise Server 11 SP1
b
Red Hat RHEL 7
Red Hat RHEL 6
b. Maintenance update is required.
Operating system Support requirements
using two ports per CHPID
Support requirements
using one port per CHPID
z/OS OSD: z/OS V1R12 OSD: z/OS V1R12
z/VM OSD: z/VM V6R2 OSD: z/VM V6R2
z/VSE OSD: z/VSE V5R1 OSD: z/VSE V5R1
z/TPF OSD: z/TPF V1R1 OSD: z/TPF V1R1
IBM zAware OSD OSD
