156 IBM z13s Technical Guide
4.7.2 Physical channel report
A PCHID reflects the physical location of a channel-type interface.
A PCHID number is based on these factors:
The I/O drawer, and PCIe I/O drawer location
The channel feature slot number
The port number of the channel feature
A CHPID does not directly correspond to a hardware channel port, but it is assigned to a
PCHID in the HCD or input/output configuration program (IOCP).
A PCHID report is created for each new build server and for upgrades on existing servers.
The report lists all I/O features that are installed, the physical slot location, and the assigned
PCHID. Example 4-2 shows a portion of a sample PCHID report. For more information about
the AID numbering rules for InfiniBand and PCIe fanouts, see Table 4-4 on page 153.
Example 4-2 PCHID REPORT
CHPIDSTART
12345678 PCHID REPORT Nov 17,2015
Machine: 2965-N20 SN1
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Source Drwr Slot F/C PCHID/Ports or AID Comment
A25/LG07 A25A LG07 0171 AID=00
A21/LG07 A21A LG07 0170 AID=04
A21/LG09 A21A LG09 0171 AID=06
A21/LG04 A21A LG04 0172 AID=1C
A21/LG03/J01 A13B 01 0403 100/Mem paired 12C/Mem
A21/LG03/J01 A13B 03 0420 108 RG1
A21/LG03/J01 A13B 06 0413 110/D1D2
A21/LG03/J01 A13B 07 0418 114/D1 115/D2
A21/LG05/J01 A13B 14 0403 12C/Mem paired 100/Mem
A21/LG05/J01 A13B 18 0411 138/D1D2 RG1
A21/LG12/J01 A13B 20 0420 140 RG2
A21/LG14/J01 A13B 37 0411 178/D1D2 RG2
Legend:
Source Book Slot/Fanout Slot/Jack
A25A CEC Drawer 2 in A frame
A21A CEC Drawer 1 in A frame
A13B PCIe Drawer 1 in A frame
0403 Flash Express
RG1 Resource Group One
0420 zEDC Express
0413 OSA Express5S GbE LX 2 Ports
0418 16 Gbps FICON/FCP LX 2 Ports
0411 10GbE RoCE Express
RG2 Resource Group Two
0171 HCA3 O PSIFB 12x 2 Links
0170 HCA3 0 LR PSIFB 1x 4 Links
0172 ICA SR 2 Links
