Chapter 10. Environmental requirements 375
10.2.1 Weights and dimensions
Installation can be on a raised floor or a non-raised floor. You can find the most up-to-date
details about the installation requirements for z13s servers in z13s Installation Manual for
Physical Planning, GC28-6953.
Table 10-3 indicates the maximum system dimensions and weights for the z13s models.
Table 10-3 IBM z13s physical dimensions and weights
10.2.2 Four-in-one (4-in-1) bolt-down kit
A bolt-down kit can be ordered for the z13s frame. The kit provides hardware to enhance the
ruggedness of the frame, and to tie down the frame to a concrete floor. The kit is offered in the
following configurations:
The Bolt-Down Kit for a raised floor installation (FC 8021) provides frame stabilization and
bolt-down hardware for securing the frame to a concrete floor beneath the raised floor.
The kit covers raised floor heights from 15.2 cm (6 in.) to 91.4 cm (36 in.).
The kit helps to secure the frame and its content from damage caused by shocks and
vibrations, such as those generated by an earthquake.
10.3 IBM zBX environmental components
The following sections provide information about the environmental components in summary
for zBX. For a full description of the environmental components for the zBX, see zBX Model
004 Installation Manual for Physical Planning, GC27-2630.
z13s single frame
Maximum Model N10 Model N20- 1 drawer Model N20- 2 drawers
W / O
IBFs
With
IBF
With IBF
and
overhead
cabling
W / O
IBF
With
IBF
With IBF
and
overhead
cabling
W / O
IBFs
With
IBF
With IBF
and
overhead
cabling
Weight in
kilograms (kg)
810 896 924 944 1030 1058 944 1030 1058
Weight in
pounds (lbs.)
1785 1975 2037 2081 2270 2232 2081 2270 2232
Height with covers
a
Width with covers
a
Depth with covers
a. The width increases by 15.2 cm (6 in.), and the height increases by 14.0 cm (5.5 in.) if overhead I/O cabling
is configured.
201.5 centimeters (cm) or 79.3 inches (in.) (42 Electronic Industries Alliance (EIA))
78.5 cm (30.9 in.)
159.5 cm (62.8 in.)
Height reduction
Width reduction
180.9 cm (71.2 in.)
None
Machine area
Service clearance
1.24 square meters (13.3 square feet)
3.22 square meters (34.7 square feet)
(IBF contained within the frame)
Note:
The Balanced Power Plan Ahead feature adds approximately 51 kg (112 lbs.)
