Programming IDEC SmartRelay
IDEC SmartRelay Manual 91
Note
For further information on the protection mode, refer to Chapter
4.3.5.
For further information on retentivity, refer to Chapter 4.3.4
You can modify the protection mode and retentivity setting only in
programming mode. This is not possible in parameter assignment
mode.
In this manual, the protection mode (“+” or “--”) and retentivity (“R”
or “-/”) settings are only shown in the displays where these can
actually be changed.
Verification of the circuit program
This program branch for Q1 is now completed. IDEC
SmartRelay shows you the output Q1. You can once again
view the circuit program on the display. Use the keys to
browse the circuit program; that is, pres
or to move from
block to block,
and to move between the inputs at a
block.
Closing the programming mode
Although you were shown how to exit the programming
mode when you cr
eated your first circuit program,
here is a reminder:
1. Return to the programming menu: Press ESC
2. Return to the main menu: Press ESC
3. Move the ’>’ cursor to ’Start’: Press
or
4. Confirm ’Start’: Press OK
IDEC SmartRelay is back in RUN mode:
2008-05-26
Mo 09:30
